Air Source Heat Pump for Swimming Pool

The use of a heating system for a swimming pool within the UK environment has, over the years, proved to be a difficult task. The use of traditional heating systems, such as gas boilers and electric heaters, is no longer economical and environmentally sustainable. The Air Source Heat Pump for Swimming Pool, however, has become the chosen alternative within the UK. In this detailed guide, we will examine everything you need to know about air source heat pumps for swimming pools, including their functionality, benefits, efficiency, costs, UK-specific factors, and a comparison between various models that have varying price tags.

What Is an Air Source Heat Pump for Swimming Pool?

An air source heat pump for swimming pool is an efficient way to heat a swimming pool using the heat energy from outside air. Unlike other sources for generating heat, it uses a refrigeration process to transfer heat energy from outside air to the swimming pool. Hence, it is far more energy-efficient than other heat sources. Even in a relatively cool climate such as the UK, the current range of air source heat pumps designed for use with swimming pools can handle temperatures as low as -5°C, so they can be used all year round, even from early spring through to autumn.

How Does an Air Source Pool Heat Pump Work?

The functioning of a pool heat pump relies on complex principles of thermodynamics:

• The ambient air is sucked into the unit by a fan.
• The air is then forced to pass over an evaporator that holds refrigerant.
• Absorbs heat from the refrigerated space to become a gas.
• The compressor raises the temperature of the gas.
• Heat is transferred to the pool water via a condenser.
• The refrigerant cools, becomes a liquid, and then starts over again.

This enables air source heat pumps designed for swimming pools to provide 5 to 7 times more heat than the electrical power consumed.

Why Air Source Heat Pumps for Swimming Pools Are Ideal for the UK

The most important reasons of Air Source Heat Pump for Swimming Pool include:

• Energy Efficiency and Low Running Costs: The cost of electricity in the UK is among the most expensive in Europe. Due to higher COP (Coefficient of Performance) ratings, an elite class pool heat pump can lower costs by up to 70% as compared to other electric methods of space heating.
• Environmentally Friendly Heating: The use of renewable heat from air greatly reduces CO₂ emissions. This harmonizes air-source swimming pool heat pumps perfectly with sustainability aims in the UK, as well as energy requirements for the future.
• Extended Swimming Season: A correctly sized inverter pool heat pump allows swimmers in the UK to enjoy a water temperature of between 26-30°C for an extensive period of the year.
• Quiet Operation: Modern full inverter heat pumps are designed for use in residential areas, running extremely quietly, which is a very important consideration for gardens and residential areas in the UK.

Key Types of Swimming Pool Heat Pumps

The most frequent cases are as follows:

• Inverter Pool Heat Pump: Using an inverter heat pump for a swimming pool, the compressor’s speed varies in accordance with the heat requirements, leading to the following:
  • Higher efficiency
  • Use less electricity
  • Quieter operation
  • Longevity
• On/Off Heat Pump: They cost less initially but use more electricity. They are less efficient later on.
• Air Source Heat Pump for Above-Ground Pools: Small to compact units intended for small volumes of water.

Choosing the Right Air Source Heat Pump for Swimming Pool

For this, it is better to consider the following:

1. Pool Size and Water Volume: Choosing the right size of the pool is imperative because it makes all the difference in:

• Small pools (up to 20 m³): 5-7 kW
• Medium pools (20-40 m³): 8-12 kW
• Large pools (40-70 m³): 12-18 kW
• Commercial pools: 18 kW+

1. 2)  UK Climate Considerations: For UK conditions, always choose:

• Full inverter technology
• Operation down to at least -5°C
• Anti-freeze protection

1. 3)  COP and Seasonal Efficiency: Check that the COP is at least 4.5 (higher would be even better, and a good sign at lower temperatures prevailing in the UK).

Popular Air Source Heat Pump for Swimming Pool Models in the UK

The most common ones of air source heat pumps for swimming pools are:

• Budget-Friendly Options:

1. Aquark Aquaintel Series (7 kW): A basic model of a pool heat pump designed for a small pool in the UK.
2. Poolstyle Inverter Heat Pump: Reliable and efficient inverter heat pumps are provided at affordable prices.

• Mid-Range Best Sellers

1. Poolex Silverline Full Inverter 12 kW: Highly popular in the UK market for its air source swimming pool heating, with a strong price/performance ratio.
2. Fairland Full Inverter Plus 10.5 kW: Renowned for excellent COP values and a long lifespan in British climate conditions.

• Premium & Smart Heat Pumps

1. Poolex Jet Pro Wi-Fi Heat Pump: It contains high-tech inverter tech with app support.
2. Remora Professional Inverter Heat Pump with Wi-Fi:  Intended for use in bigger pools, designed for commercial purposes.

Air Source Heat Pump for Swimming Pool: Price Comparison (UK)

Prices of air source heat pumps for swimming pools can depend on VAT, installation charges, and promotional offers from UK retailers:

Installation of an Air Source Heat Pump for Swimming Pool

Installation is relatively easy, but it has to be in accordance with UK electrical and safety regulations. Key Requirements for Installation: To be installed outdoors with good air flow around it, with a stable concrete base; the pipe has to be correctly sized, and electrical protection has to be installed. Installation by professionals is recommended, especially for large or commercial air source pool heat pumps.

Maintenance and Lifespan

One of the greatest benefits that can be found in the Air Source Heat Pump for Swimming Pool is its low maintenance. In fact, with appropriate care, the lifespan of the unit is estimated to be 10-15 years. Basic Maintenance Advice:

•  Change filters often
•  Unobstructed airflow
•  Check water flow rate
•  Annual Professional Inspection

Reducing Running Costs in the UK

These can save hundreds of pounds annually in heating costs. In order to maximize efficiency, use a solar pool cover, operate the heat pump during the day, Can be combined with solar PV panels to ensure the stability of water temperature.

Final Thoughts: Is an Air Source Heat Pump for Swimming Pool Worth It?

For UK swimming pool owners, there is no doubt: yes. A properly selected Air Source Heat Pump for Swimming Pools delivers:

• It consumes less energy
• Reduced carbon footprint
• Longer swimming season
• Noiseless, dependable operation

First of all, no matter if the target is a home pool or a commercial swimming pool, a good investment would be a modern inverter-type swimming pool heat pump.
